China Professional Compact and Efficient Planetary Gearbox for Packaging Machinery planetary gearbox buy online

Product Description




Product Description

Product Parameters

Parameters Unit Level Reduction Ratio Flange Size Specification
060 090 115 142 180 220
Rated output torque T2n N.m 1 3 55 130 208 342 750 1140
4 50 140 290 542 1050 1700
5 60 160 330 650 1200 2000
6 55 140 300 550 1100 1800
7 50 140 300 550 1100 1800
8 45 120 260 500 1000 1600
10 40 100 230 450 900 1500
2 12 55 130 208 342 1050 1700
15 60 160 330 650 1200 2000
20 60 160 330 650 1200 2000
25 60 160 330 650 1200 2000
28 50 140 300 550 1100 1800
30 55 130 230 450 900 1500
35 60 160 330 650 1200 2000
40 60 160 330 650 1200 2000
50 60 160 330 650 1200 2000
70 50 140 300 550 1100 1800
100 40 100 230 450 900 1500
3 120 55 140 290 542 1050 1700
150 60 160 330 650 1200 2000
200 60 160 330 650 1200 2000
250 60 160 330 650 1200 2000
280 50 140 300 550 1100 1800
350 60 160 330 650 1200 2000
400 60 160 330 650 1200 2000
500 60 160 330 650 1200 2000
700 50 140 300 550 1100 1800
1000 40 100 230 450 900 1500
Maximum output torque T2b N.m 1,2,3 3~1000 3Times of Rated Output Torque
Rated input speed N1n rpm 1,2,3 3~1000 4000 3000 3000 3000 3000 2000
Maximum input speed N1b rpm 1,2,3 3~1000 8000 6000 6000 6000 6000 4000
Ultra Precision Backlash PS arcmin 1 3~10 ≤1 ≤1 ≤1 ≤1 ≤1 ≤1
arcmin 2 12~100 ≤2 ≤2 ≤2 ≤2 ≤2 ≤2
arcmin 3 120~1000 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5
High precision backlash P0 arcmin 1 3~10 ≤2 ≤2 ≤2 ≤2 ≤2 ≤2
arcmin 2 12~100 ≤3 ≤3 ≤3 ≤3 ≤3 ≤3
arcmin 3 120~1000 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7
Precision backlash P1 arcmin 1 3~10 ≤3 ≤3 ≤3 ≤3 ≤3 ≤3
arcmin 2 12~100 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5
arcmin 3 12~1000 ≤9 ≤9 ≤9 ≤9 ≤9 ≤9
Standard backlash P2 arcmin 1 3~10 ≤5 ≤5 ≤5 ≤5 ≤5 ≤5
arcmin 2 12~100 ≤7 ≤7 ≤7 ≤7 ≤7 ≤7
arcmin 3 120~1000 ≤11 ≤11 ≤11 ≤11 ≤11 ≤11
Torsional rigidity Nm/arcmin 1,2,3 3~1000 3.5 10.5 20 39 115 180
Allowable radial force F2rb2 N 1,2,3 3~1000 1100 2200 5571 7610 10900 24000
Allowable axial force F2ab2 N 1,2,3 3~1000 630 1230 2550 3780 5875 11200
Moment of Inertia J1 kg.cm2 1 3~10 0.2 1.2 2 7.2 25 65
2 12~100 0.08 0.18 0.7 1.7 7.9 14
3 120~1000 0.03 0.01 0.04 0.09 0.21 0.82
Service Life hr 1,2,3 3~1000 20000
Efficiency η % 1 3~10 97%
2 12~100 94%
3 120~1000 91%
Noise Level dB 1,2,3 3~1000 ≤58 ≤60 ≤63 ≤65 ≤67 ≤70
Operating Temperature ºC 1,2,3 3~1000 -10~+90
Protection Class IP 1,2,3 3~1000 IP65
Weights kg 1 3~10 1.3 3.9 8.7 16 31 48
2 12~100 1.8 4.6 10 20 39 62
3 120~1000 2.3 5.3 10.5 21 41 66

FAQ

Q: How to select a gearbox?

A: Firstly, determine the torque and speed requirements for your application. Consider the load characteristics, operating environment, and duty cycle. Then, choose the appropriate gearbox type, such as planetary, worm, or helical, based on the specific needs of your system. Ensure compatibility with the motor and other mechanical components in your setup. Lastly, consider factors like efficiency, backlash, and size to make an informed selection.

Q: What type of motor can be paired with a gearbox?

A: Gearboxes can be paired with various types of motors, including servo motors, stepper motors, and brushed or brushless DC motors. The choice depends on the specific application requirements, such as speed, torque, and precision. Ensure compatibility between the gearbox and motor specifications for seamless integration.

Q: Does a gearbox require maintenance, and how is it maintained?

A: Gearboxes typically require minimal maintenance. Regularly check for signs of wear, lubricate as per the manufacturer’s recommendations, and replace lubricants at specified intervals. Performing routine inspections can help identify issues early and extend the lifespan of the gearbox.

Q: What is the lifespan of a gearbox?

A: The lifespan of a gearbox depends on factors such as load conditions, operating environment, and maintenance practices. A well-maintained gearbox can last for several years. Regularly monitor its condition and address any issues promptly to ensure a longer operational life.

Q: What is the slowest speed a gearbox can achieve?

A: Gearboxes are capable of achieving very slow speeds, depending on their design and gear ratio. Some gearboxes are specifically designed for low-speed applications, and the choice should align with the specific speed requirements of your system.

Q: What is the maximum reduction ratio of a gearbox?

A: The maximum reduction ratio of a gearbox depends on its design and configuration. Gearboxes can achieve various reduction ratios, and it’s important to choose 1 that meets the torque and speed requirements of your application. Consult the gearbox specifications or contact the manufacturer for detailed information on available reduction ratios.
